[자료구조] Stack

Stack Data Structure

A stack is a linear data structure that follows the principle of Last In First Out (LIFO).

This means the last element inserted inside the stack is removed first.

You chan think of the stack data struccture as the pile of plates on top of another.





Here, you can:

• Put a new plate on top.
• Remove the top plate.

And, if you want the plate at the bottom, you must first remove all the plates on top.(LIFO) This is exactly how the stack data structure works.



LIFO Principle of Stack



In programming terms, putting an item on top of the stack is called push and removing an item is called pop.





In the above image, although item 3 was kept last, it was removed first. This is exactly how the LIFO principle works.

Basic Operations of Stack

There are some basic operations that allow us to perform different actions on a stack.

• Push : Add an element to the top of a stack.
• Pop : Remove an element from the top of a stack.
• IsEmpty : Check if the stack is empty.
• IsFull : Check if the stack is full.
• Peek : Get the value of the top element without removing it.

Working of Stack Data Structure.

The operations work as follows.

1. A pointer called TOP is used to keep track of the top element in the stack.
2. When initializing the stack, we set its value to -1 so that we can check if the stack is empty by comparing TOP == -1.
3. On pushing an element, we increase the value of TOP and place the new element in the position pointed to by TOP.
4. On popping an elementm we return the element pointed to by TOP and reduce its value.
5. Before pushing, we check if the stack is already full.
6. Before popping, we check if the stack is already empty.



Example Code

class Stack<T>  {
    private arr: Array<T>;
    private top: number;
    private size: number;

    constructor(size: number){
        this.size = size;
        this.top = -1;
        this.arr = new Array<T>(size);
    }

    push(item:T) {
        if(this.isFull()){
            console.log('stack is full');
            throw new Error('Stack is full');
        }
        this.top++;
        this.arr.push(item);
    }

    pop():T {
        if(this.isEmpty()){
            console.log('stack is empty');
            throw new Error('Stack is empty');
        }

        let popResult = this.arr[this.top--];

        return popResult;

    }

    isEmpty(): boolean {
        return (this.top == -1);
    }

    isFull(): boolean {
        return (this.top+1 == this.size);
    }

    peek(): T | undefined {
        if(this.isEmpty()){
            console.log('stack is empty');
            throw new Error('Stack is empty');
        }

        let peekResult = this.arr[this.top];

        return peekResult;
    }
}
